Marquis C538-T
Marquis C538-SR4
High performance Alder Lake uni-processor workstation
- Intel Z690 chipset providing excellent performance and stability
- Intel® 12th generation Core® i5/i7/i9 processor
- Dual channel memory controller
- Up to 128GB DDR5 ultra fast memory
- Up to 8 hyper-threaded Performance cores
- Up to 8 single-threaded Efficient cores
- Blazing fast NVME PCIe SSD OS storage
- ASUS Hyper M.2 X16 for extra NVMe storage (N6 model)
- One PCI Express x16 v5.0 expansion slot
- Onboard Intel UHD770 3D graphics accelerator
- Optional Nvidia GeForce/Quadro/Tesla accelerator
- Onboard Intel 2.5Gigabit Ethernet controller
- Onboard Realtek 7.1 channel HD audio controller
- Onboard USB 3.2 controllers
- External USB DVD+-RW dual layer optical burner
- Pedestal Tower Chassis with high performance power supply
- Angular mesh front panel for maximum air intake (T model)
- Seasonic (Platinum Level) full modular power supply
- SAS3 enclosure supporting up to 4 hotswap drives (SR4 model)
- Noctua 12cm CPU cooler for optimal thermal & acoustic performance
- Front panel USB3.2 Gen 1 port
- 64-bit Linux operating system
Three year limited warranty
full specs tech notes
Compare all ASL workstation models
|
Marquis C538-T |
Marquis C538-SR4 |
Processor |
Intel® Core i7-12700K (8 Performance cores, 4 Efficient cores) |
Intel® Core i7-12700K (8 Performance cores, 4 Efficient cores) |
Memory |
16GB DDR5-4800 non-ECC SDRAM |
16GB DDR5-4800 non-ECC SDRAM |
Storage Controller |
Onboard Z690 PCH SATA 6Gbs |
Broadcom 9361 SAS3/SATA 12Gb/s RAID |
Drive Bays |
Four M.2 NVMe + Two fixed 3.5/2.5in HD |
Four M.2 NVMe + Four hotswap 3.5in HD |
Hard Disk |
500GB NVME PCIe SSD (OS) |
500GB NVME PCIe SSD (OS) |
Starting Price |
|
|
